UPRIGHT, 12 FT X 48” W REDI-RACK STYLE 22,000LBS PER SECTION

Products Details

RR-UPRIGHT, 12 FT H X 48” D REDI-RACK STYLE 22,000 LB/ SECTION

16 FT TALL X 48″ WIDE (DEEP) CAPACITY: 22,000 LBS/ SECTION – BOLTED FRAME STYLE

14 GAUGE, 3.35″ (85mm) x 2.64″ (67mm), 3″ (76.2mm) PITCH – REDI-RACK DIMENSIONS

UNASSEMBLED.

OVER-SIZE PART – REQUIRES CUSTOM FREIGHT QUOTE – PRIOR TO PURCHASE.

PLEASE COMPLETE SALE – AND – ZILLA PERSONNEL WILL UPDATE THE CUSTOMIZED FREIGHT COST ASAP.

PDF (Assembly Instr): ZRR-UR-12HX48W-SALES.PDF

STEP (3D CAD): ZRR-UR-12HX48W.STEP
